E850-45-5(22x27)
Expander lasermodule, infrared Laserdiode, 850nm, 45mW, 22x27mm, Laser Class 1M
Are you surprised that we communicate our prices so openly? Other suppliers only give you individual quotations? Our costing is also based on transparency, trust and treating all customers equally and this gives you the ability to compare!
| Pcs: | 10 | 50 | 100 | 250 | 500 | 1000 |
| Discount: | 10% | 15% | 20% | 25% | 30% | 35% |
| Warranty | 1Jahre |
| Beam Shape | Dot |
| Wavelength | 650nm (rot) |
| Optical Power | 1mW |
| Laser Class | 2 |
| Divergence | 1mrad |
| Beam Diameter | 3mm |
| Size of Laserdot | <4..6mm@5m |
| Operating Distance | 10m |
| Optics | acryl lense |
| Laser technology | diode |
| Size | Ø15mm 67mm |
| Material | aluminium |
| Focus | collimated |
| Output Aperture | 3mm |
| Potential of Housing | VDD(+) |
| Lifetime | >3000h |
| Operating Voltage | 3 - 4.5V DC |
| Operating Current | 10 - 30, typ 20mA |
| Battery | LR44/AG13 alkaline battery, 1.5V |
| Housing Color | black |
| Operating Temperature | -20°C - 40°C |
| Storage Temperature | -40°C - 80°C |
| Weight | 27g |
