DB520-10-24-FA(20x80)-F22000-M12
isolated dot lasermodule, green, 520nm, 10mW, 24V DC, 20x80mm, class 3R, Water…
¿Le sorprende que informemos de nuestros precios de manera tan clara? ¿Sólo recibe ofertas individuales de otros proveedores? Nuestro cálculo de costos se basa en la transparencia, la confianza y la igualdad de trato de todos nuestros clientes - ¡y así usted tiene la opción de comparar!
| Unidades: | 10 | 50 | 100 | 250 | 500 | 1000 |
| Descuento: | 10% | 15% | 20% | 25% | 30% | 35% |
| Warranty | 1Jahre |
| Beam Shape | Línia |
| Wavelength | 650nm (rot) |
| Optical Power | 35mW |
| Laser Class | 3R |
| Divergence | 1mrad |
| Fan Angle | 60° |
| Line Thickness | ≤20μm (@35mm) |
| Operating Distance | 0.035m |
| Optics | Powell Lens |
| Size | Ø15mm 60mm |
| Material | aluminium |
| Cable length | 200mm |
| Wire type | 24AWG, black, 3mm |
| Focus | fixed (35mm) |
| Max. Mod. Frequency | 20kHz |
| Lifetime | >10000h |
| Operating Voltage | 4.5 - 5.5, typ 5V DC |
| Operating Current | 100 - 140, typ 120mA |
| Housing Color | negro |
| Operating Temperature | -20°C - 60°C |
| Storage Temperature | -40°C - 85°C |
| Weight | 20g |
| Power Supply | Power Supply with stripped/tinned wires, Output: 5V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3W max. |
| Stripping of wire | 5mm |
![]() | MULTI-MOUNT-15(45x75) Pedido Nr.: 70114102 Mount for Lasermodul 15mm, Diameter 45mm, Height 75mm 61.26 EUR |
| DOE254-635-5-24(16x65)-NT Pedido Nr.: 70142594 focusable isolated DOE lasermodule, red, 635nm, 5mW, 24V DC, 16x65mm, class 2M, with DOE R254 226.81 EUR |
| DD635-5-24(16x65)-DOE283 Pedido Nr.: 70143393 focusable isolated DOE lasermodule, red, 635nm, 5mW, 24V DC, 16x65mm, class 2M, with DOE283 Line 20°@633nm 176.39 EUR |
| DOE-DE-R258 Pedido Nr.: 70108156 Diffractive Optical Element DOE 11x11 Dots PC 8x1.2mm 39.2° @635nm 46.13 EUR |
| LH520-20-24(20x80)-C3000 Pedido Nr.: 70128277 isolated Line lasermodule, green, 90°, 520nm, 20mW, 24V DC, 20x80mm, class 2 386.47 EUR |
| KS-MOUNT-20(36X62)-MAGNETIC Pedido Nr.: 70160253 Magnetic mount for laser module 20mm, diameter 36mm, height 62mm, plastic, holding force 6.5 kg 16.72 EUR |
| DOE-SET02 Pedido Nr.: 70122022 Adjustment Tool for DOE mounting 3.98 EUR |
| DD850-5-3(12x38)-DOE335 Pedido Nr.: 70143126 focusable isolated DOE lasermodule, infrared, 850nm, 5mW, 3V DC, 12x38mm, class 3R, with DOE335 201.60 EUR |
| PICOMARK-650-1000-135DEG Pedido Nr.: 70159431 collimated isolated Line lasermodule, red, 135°, 650nm, 1000mW, 230V, 80x80mm, class 3B 1,030.40 EUR |
