E450-60-5(16x25)

Order number: 70141160

Product description:
Expander lasermodule, blue Laserdiode, 450nm, 60mW, 16x25mm, Laser Class 3R

• Operating Voltage 5 V DC
• compact size
• Laser Class 3R
• High Power
E450-60-5(16x25) - Hauptbild
Warnlabel 3R
235,21
All prices in euros plus VAT at current rate and shipping costs.

We don't need to hide our prices!

Are you surprised that we communicate our prices so openly? Other suppliers only give you individual quotations? Our costing is also based on transparency, trust and treating all customers equally and this gives you the ability to compare!

Pcs: 10501002505001000
Discount: 10%15%20%25%30%35%
  • Specification
  • Warranty 1Jahre
    Beam Shape Dot
    Wavelength 450nm
    (blau)
    Optical Power 60mW
    Laser Class 3R
    Divergence 0.5mrad
    Size of Laserdot <15mm@10m
    Operating Distance 10m
    Optics Glass lens AR coated
    Laser technology diode
    Size Ø16mm 25mm
    Material Bronze
    Cable length 115mm
    Focus collimated
    Output Aperture 5mm
    Potential of Housing VDD(+)
    Lifetime >10000h
    Operating Voltage 4 - 6, typ 5V DC
    Operating Current 100 - 500, typ 400mA
    Housing Color brass
    Operating Temperature -20°C - 60°C
    Storage Temperature -20°C - 85°C
    Weight 31.5g
    Power Supply Power Supply with stripped/tinned wires, Output: 5V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3W max.
    Bracket LF-BRACKET09
  • Illustration and technical drawing
  • E450-60-5(16x25) - Hauptbild
    Warnlabel 3R
    Connector pin assignment
    Ground:Cable color Ground: blackblackGND
    Positive:Cable color Positive: redred5V DC
  • Matching accessories
  • MULTI-MOUNT-16(45x75)MULTI-MOUNT-16(45x75)
    Order no.: 70112504
    Mount for Lasermodul 16mm, Diameter 45mm, Height 75mm
    66.30 EUR
