DOE289-532-5-3-F(12X55)
focusable isolated DOE lasermodule, green, 532nm, 5mW, 3V DC, 12x53.5mm, class…
Verbaast het u om hier openlijke prijzen te vinden? Bij andere aanbieders ontvangt u uitsluitend individuele offertes? Onze calculaties zijn gebaseerd op transparantie, vertrouwen en gelijke behandeling van onze klanten - en u heeft de mogelijkheid om te vergelijken!
| Stuks: | 10 | 50 | 100 | 250 | 500 | 1000 |
| Korting: | 10% | 15% | 20% | 25% | 30% | 35% |
| Warranty | 1Jahre |
| Beam Shape | Punt |
| Wavelength | 532nm (grün) |
| Optical Power | 50mW |
| Laser Class | 3B |
| Divergence | 1mrad |
| Beam Diameter | 5mm |
| Size of Laserdot | <5mm@5m |
| Operating Distance | 100m |
| Optics | Lensglas met AR-coating |
| Beam Mode | TEM00 |
| Laser technology | Solid State (YVO4+KTP) |
| Size | Ø20mm 112mm |
| Material | aluminium |
| Focus | collimated |
| Output Aperture | 5mm |
| Lifetime | >5000h |
| Operating Voltage | 4.5 - 5.5, typ 5V DC |
| Operating Current | 100 - 300, typ 150mA |
| Housing Color | rood |
| Connector | CON-USB-A |
| Operating Temperature | 15°C - 30°C |
| Storage Temperature | -40°C - 80°C |
| Warm up time | <15min |
| Weight | 74g |
