DOE218-635-5-6(10x24)-ADJ

Order number: 70133981

Product description:
DOE Laser Module 635nm, red, 5mW, DOE Cross - PMMA - 8x1mm 15° @640nm, 5V DC, Ø10x24mm, Laser Class 2M with DOE-DE-R218
DOE218-635-5-6(10x24)-ADJ - Hauptbild
Warnlabel 2M
104,96
All prices in euros plus VAT at current rate and shipping costs.

We don't need to hide our prices!

Are you surprised that we communicate our prices so openly? Other suppliers only give you individual quotations? Our costing is also based on transparency, trust and treating all customers equally and this gives you the ability to compare!

Pcs: 10501002505001000
Discount: 10%15%20%25%30%35%
  • Specification
  • Warranty1Jahre
    Beam ShapeDOE
    Wavelength635nm
    (rot)
    Optical Power5mW
    Laser Class2M
    Divergence1mrad
    Opticsacryl lense
    Laser technologySingle Mode Diode
    Protection LensJa
    Size
    MaterialBronze
    Cable length100mm
    Wire type26AWG, 0,14mm²
    Focusadjustable
    Output Aperture6mm
    Potential of HousingVDD(+)
    Lifetime>3000h
    Operating Voltage3 - 6, typ 5V DC
    Operating Current15 - 70, typ 30mA
    Housing Colorbrass
    Operating Temperature-20°C - 50°C
    Storage Temperature-40°C - 80°C
    Weight8.5g
    Alpha8.3°
    Beta8.3°
    Gamma11.8°
    Delta0.36°
    a14.6mm
    b14.6mm
    c20.6mm
    d0.6mm
    Diameter (without holder)8mm
    MaterialPC
    Stripping of wire5mm
  • Illustration and technical drawing
  • DOE218-635-5-6(10x24)-ADJ - Hauptbild
    Warnlabel 2M
    Connector pin assignment
    Ground:Cable color Ground: blackblackGND
    Positive:Cable color Positive: redred5V DC
  • Matching accessories
  • AM1-1203SZAM1-1203SZ
    Order no.: 70114928
    DC DC Converter IN=12V OUT=3V 1 Watt (300 mA)
    16.72 EUR
