LE635-25-3(14x45)
isolated Line lasermodule, red, 90°, 635nm, 25mW, 3V DC, 14x45mm, focus 3m, cla…
DI650-0.4-5(8X21)-AP-CON
Numéro de commande: 70157314
Description du produit:
isolated dot lasermodule, red, 650nm, 0.4mW, 5V DC, 8x21mm, class 1, axial parallel, DC-connector 2.1mm
Description du produit:
isolated dot lasermodule, red, 650nm, 0.4mW, 5V DC, 8x21mm, class 1, axial parallel, DC-connector 2.1mm
-F700-AP.png "DI650-0.4-5(8X21)-AP-CON - Zeichnung")
-F700-AP.png "DI650-0.4-5(8X21)-AP-CON - Zeichnung Front")
-F700-AP.png "DI650-0.4-5(8X21)-AP-CON - Zeichnung isometrisch")
Nous n'avons rien à cacher en matière de prix!
Vous vous étonnez de trouver ici des prix communiqués ouvertement ? Vous obtenez uniquement des offres individuelles auprès d'autres fournisseurs ? Notre évaluation des prix est également basée sur la transparence, la confiance et le même traitement de tous nos clients – et vous avez la possibilié de comparer!
| Unité: | 10 | 50 | 100 | 250 | 500 | 1000 |
| Réduction: | 10% | 15% | 20% | 25% | 30% | 35% |
- Spécification
Warranty 1Jahre Beam Shape Point Wavelength 650nm
(rot)Optical Power 0.4mW Laser Class 1 Divergence 1.5mrad Beam Diameter 2mm Size of Laserdot <3..5mm@5m Operating Distance 10m Optics Lentille de verre revêtue d'AR Laser technology Single Mode Diode Axial Divergence ±0.15° Size Ø8mm 21mm Material aluminium Cable length 100mm Wire type 26AWG, 0,14mm² Focus collimated Output Aperture 2.5mm Potential of Housing isolé Lifetime >5000h Operating Voltage 4.5 - 5.5, typ 5V DC Operating Current 5 - 25, typ 15mA Housing Color silver Connector 2.1 mm DC socket (GND inner) Operating Temperature -20°C - 50°C Storage Temperature -40°C - 80°C Weight 3g Power Supply Power Supply, Output: 5V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3W max, Connector 2,1x5,5x9,5mm center negative - Illustration et dessin technique
- Affectation des connecteurs
Dimensions:
bleu GND Positif:
rouge 5V DC - Accessoires adaptés
MULTI-MOUNT-08(45x75)
Référence: 70112481
Mount for Lasermodul 8mm, Diameter 45mm, Height 75mm
61.26 EUR- Downloads
