PICO-LPG-820-1750
Número de pedido: 70149517
Descripción del producto:
Laser Safety Eyewear, complete protection, universal fit, comfortable fit over prescription glasses or alone, adjustable temples, side-shields for wide field of view, CE Certified EN 207:2009,Fitover - 144mm x 145mm x 50mm, with Picotronic Logo imprint
* ● Wavelength: 190-315nm, lb rating D LB8 + IR LB3 ● Wavelength: 775-795nm, lb rating DIR LB4 ● Wavelength: 820-1750nm, lb rating D LB5 + IR LB6
* Especially suitable for: Laser INFRARED 850nm - 1750nm
• Complete protection
• Comfortable fit over glasses or alone
• Adjustable temples and Side-shields for wide field of view
• CE Certified EN 207
• with Picotronic Logo imprint
Descripción del producto:
Laser Safety Eyewear, complete protection, universal fit, comfortable fit over prescription glasses or alone, adjustable temples, side-shields for wide field of view, CE Certified EN 207:2009,Fitover - 144mm x 145mm x 50mm, with Picotronic Logo imprint
* ● Wavelength: 190-315nm, lb rating D LB8 + IR LB3 ● Wavelength: 775-795nm, lb rating DIR LB4 ● Wavelength: 820-1750nm, lb rating D LB5 + IR LB6
* Especially suitable for: Laser INFRARED 850nm - 1750nm
• Complete protection
• Comfortable fit over glasses or alone
• Adjustable temples and Side-shields for wide field of view
• CE Certified EN 207
• with Picotronic Logo imprint
¡No hace falta que ocultemos nuestros precios!
¿Le sorprende que informemos de nuestros precios de manera tan clara? ¿Sólo recibe ofertas individuales de otros proveedores? Nuestro cálculo de costos se basa en la transparencia, la confianza y la igualdad de trato de todos nuestros clientes - ¡y así usted tiene la opción de comparar!
| Unidades: | 10 | 50 | 100 | 250 | 500 | 1000 |
| Descuento: | 10% | 15% | 20% | 25% | 30% | 35% |
- Características
Size 145 x 144 x 50mm Material Polymer Housing Color negro Operating Temperature -50°C - 85°C Storage Temperature -50°C - 80°C Weight 10g Luminous transmittance 0.16% LB Rating 190-315 D LB8 + IR LB3
>315-480 D LB5 + IR LB6
775-795 DIR LB4
>795-820 DIR LB5
>820-1400 D LB5 + IR LB6
>1400-1880 DIR LB2Lens Color Green - Imágenes y dibujo técnico
