DD850-0.35-4(14x30)-AP-CON
Número de pedido: 70140590
Descripción del producto:
isolated Dot lasermodule, infrared, 850nm, 0.35mW, 4V DC, 14x30mm, class 1
• Operating Voltage 4 V DC
• Laser Class 1
• image processing
• glas lenses anti reflex coated
• uniform illumination
Descripción del producto:
isolated Dot lasermodule, infrared, 850nm, 0.35mW, 4V DC, 14x30mm, class 1
• Operating Voltage 4 V DC
• Laser Class 1
• image processing
• glas lenses anti reflex coated
• uniform illumination
-C170.png "DD850-0.35-4(14x30)-AP-CON - Zeichnung")
-C170.png "DD850-0.35-4(14x30)-AP-CON - Zeichnung Front")
-C170.png "DD850-0.35-4(14x30)-AP-CON - Zeichnung isometrisch")
¡No hace falta que ocultemos nuestros precios!
¿Le sorprende que informemos de nuestros precios de manera tan clara? ¿Sólo recibe ofertas individuales de otros proveedores? Nuestro cálculo de costos se basa en la transparencia, la confianza y la igualdad de trato de todos nuestros clientes - ¡y así usted tiene la opción de comparar!
| Unidades: | 10 | 50 | 100 | 250 | 500 | 1000 |
| Descuento: | 10% | 15% | 20% | 25% | 30% | 35% |
- Características
Warranty 1Jahre Beam Shape Punto Wavelength 850nm
(infrarot)Optical Power 0.35mW Laser Class 1 Divergence 0.5mrad Beam Diameter 3mm Operating Distance 10m Optics Lente de cristal con recubrimiento AR Laser technology Single Mode Diode Opt. Power Stability at const. Temp. <1% Stability <8% @ -10 - 50°C Axial Divergence ±2° Rise Time <100ms Size Ø14mm 30mm Material aluminium Cable length 150mm Wire type Belden, Typ 1095, 28AWG Focus collimated Output Aperture 3mm Potential of Housing aislado Lifetime >50000h Operating Voltage 3.5 - 4.5, typ 4V DC Operating Current 12mA Housing Color negro Operating Temperature -10°C - 50°C Storage Temperature -40°C - 60°C Weight 11.3g Pointing Stability <0.2° - Imágenes y dibujo técnico
- Asignación de conectores
Dimensiones:
negro GND Stecker Pin Dimensiones: 2 Positivo:
rojo 4V DC Stecker Pin Positivo: 1 - Accesorios idóneos
MULTI-MOUNT-14(45x75)
Pedido Nr.: 70114096
Mount for Lasermodul 14mm, Diameter 45mm, Height 75mm
61.26 EUR- Downloads
