DOE396-635-10-5-F(16X62)

Order number: 70184693

Product description:
Adjustable isolated DOE laser module, red, 635nm, 10mW, 5V DC, 16x62mm, Class 2, including DOE-DE-R396

• Operating Voltage 5 V DC
• adjustable focus
• DOE optic can be changed
• compact size
• glas lenses anti reflex coated
DOE396-635-10-5-F(16X62) - Hauptbild
Warnlabel 2
268,82
All prices in euros plus VAT at current rate and shipping costs.

We don't need to hide our prices!

Are you surprised that we communicate our prices so openly? Other suppliers only give you individual quotations? Our costing is also based on transparency, trust and treating all customers equally and this gives you the ability to compare!

Pcs: 10501002505001000
Discount: 10%15%20%25%30%35%
  • Specification
  • Warranty1Jahre
    Beam ShapeDOE
    Wavelength635nm
    (rot)
    Optical Power10mW
    Laser Class2
    Divergence0.5mrad
    Operating Distance1m
    OpticsGlass lens AR coated
    SizeØ16mm 62mm
    Materialaluminium
    Cable length300mm
    Wire type18AWG, black, 3,6mm
    Focusadjustable
    Output Aperture5mm
    Potential of Housinginsulated
    Lifetime>10000h
    Operating Voltage4.5 - 5.5, typ 5V DC
    Operating Current10 - 80, typ 45mA
    Housing Colorblack
    Operating Temperature-20°C - 50°C
    Storage Temperature-40°C - 80°C
    Weight25g
    Power SupplyPower Supply with stripped/tinned wires, Output: 5V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3W max.
    Alpha37.5°
    Beta32.7°
    Gamma1.9°
    Delta19.2°
    Diameter (without holder)8mm
    MaterialPC
    Stripping of wire5mm
    Stripping of cable cover50mm
  • Illustration and technical drawing
  • DOE396-635-10-5-F(16X62) - Hauptbild
    Warnlabel 2
    Connector pin assignment
    Ground:Cable color Ground: blackblackGND
    Positive:Cable color Positive: whitewhite5V DC
