DD635-5-5(16X62)-DOE-USB
focusable isolated DOE lasermodule, red, 635nm, 5mW, 5V DC, 16x62mm, class 3R,…
Are you surprised that we communicate our prices so openly? Other suppliers only give you individual quotations? Our costing is also based on transparency, trust and treating all customers equally and this gives you the ability to compare!
| Pcs: | 10 | 50 | 100 | 250 | 500 | 1000 |
| Discount: | 10% | 15% | 20% | 25% | 30% | 35% |
| Warranty | 1Jahre |
| Beam Shape | Fiber |
| Wavelength | 450nm (blau) |
| Optical Power | 50mW |
| Laser Class | 3B |
| Optics | Glass lens AR coated |
| Beam Mode | TEM00 |
| Laser technology | Single Mode Diode |
| Size | Ø14mm 147mm |
| Material | aluminium |
| Potential of Housing | insulated |
| Lifetime | >8000h |
| Operating Voltage | 2.7 - 3.3, typ 3V DC |
| Operating Current | 100 - 160, typ 130mA |
| Battery | AA battery, 1.5V |
| Housing Color | black |
| Operating Temperature | -10°C - 50°C |
| Storage Temperature | -40°C - 80°C |
| Weight | 7g |
| Fiber core diameter | Ø200µm |
| Fiber length | 3m |
| Fiber included | Ja |
![]() | MULTI-MOUNT-14(45x75) Order no.: 70114096 Mount for Lasermodul 14mm, Diameter 45mm, Height 75mm 66.30 EUR |
| MDC658-40-5(14x45) Order no.: 70123982 modulated dot laser, red, 658nm, 40mW, 5V DC, 14x45mm, class 3B 336.05 EUR |
| LC650-5-5-F(14x45)-NT Order no.: 70107302 focusable isolated Line lasermodule, red, 90°, 650nm, 5mW, 5V DC, 14x45mm, class 1 131.01 EUR |
| PICOMARK-650-1000-135DEG Order no.: 70159431 collimated isolated Line lasermodule, red, 135°, 650nm, 1000mW, 230V, 80x80mm, class 3B 1,109.16 EUR |
| MULTI-MOUNT-18(45x75) Order no.: 70114119 Mount for Lasermodul 18mm, Diameter 45mm, Height 75mm 66.30 EUR |
| LE650-5-3(20x75)45-F500-C2000 Order no.: 70108828 isolated Line lasermodule, red, 45°, 650nm, 5mW, 3V DC, 20x75mm, class 1 82.27 EUR |
| DOE252-635-5-6(10x24)-ADJ-NT Order no.: 70144765 DOE Laser Module 635nm, red, 5mW,DOE 5 LINES - PC - 8x1,2mm 24.1° @635nm, 5V DC, Ø10x24mm, Laser Class 2M with DOE-DE-R252 , incl. power supply 113.36 EUR |
| DD850-0.35-4(14x30)-AP-CON Order no.: 70140590 isolated Dot lasermodule, infrared, 850nm, 0.35mW, 4V DC, 14x30mm, class 1 57.90 EUR |
| DDI635-1-24(12x45)-C3000 Order no.: 70115956 focusable isolated Dot lasermodule, red, 635nm, 1mW, 24V DC, 12x45mm, cable 3m, class 2 89.83 EUR |
